RIE Plasma Etching System RIE-10NR
Novel low-cost and high-performance
概要
The RIE-10NR is a novel low-cost, high-performance, fully automatic reactive ion etching system which meets the most demanding process requirements for non-corrosive gas chemistry. A computerized touch screen provides a user-friendly interface for parameter control and storage. The system enables accurate sidewall profile control and high etch selectivity between materials. With its sleek, compact design, the RIE-10NR requires minimal cleanroom space.
主要特点和优点
- Processing up to ø220 mm (ø3” x 5, ø4” x 3, ø8” x 1)
- Highly selective anisotropic etching meets demanding process requirements
- Fully automatic “one-button” operation with full manual override
- A computerized touch screen provides a user-friendly interface for parameter control and storage
- Automatic pressure control that allows for precise control of process pressure independent of gas flow
- Dry pump and system layout allow for ease of maintenance
- The reliable and durable system with a global installed base of more than 400 systems
应用
- Etching of various materials such as Si, SiO2, SiN, Poly-Si, GaAs, Mo, Pt, Polyimide, etc.
- Selective layer etching in failure analysis
- Photoresist ashing, stripping, and descuming
- Surface modification (wettability and adhesion improvement)
